Minehound VMR3 –
Dual-Sensor Mine Detector

VMR3 Dual Sensor Mine Detector Datasheet Handheld EOD Brochure

Minehound VMR3 –
Dual-Sensor Mine Detector

Dual-Sensor Detector with LED Display. The VMR3 “Minehound” dual-sensor detector is internationally proven. It is ideal for the simultaneous detection of metal and metal-free objects. This is a decisive advantage e.g. for the detection of IEDs.

    • ✔Ground Penetrating Radar and Metal Detection
    • ✔Rugged mechanical design with high-quality carbon telescoping carrying bar
    • ✔High sensitivity for high-efficiency soil compensation
    • ✔Integrated OLED display for simplified operation
    • ✔Easily noticeable alarm indication (audio/visual/vibration)
Click to enlarge
Chelton are a trusted partner of Vallon GmbH, providing Ground Penetrating Radar technologies and services for over 15 years. For enquiries not related to the UK market (either for end use or via UK Government Export), Chelton recommend contacting Vallon GmbH initially at the following address: [email protected].

Suitable for the following
searches

Mines12

Suited for mine detection. Thanks to maximum sensitivity, also reacts to mines with low or no metal content.

UXO

Ideal for shallow searching for all types of metal (e. g. unexploded ordnances, submunitions, etc.).

IED

Thanks to a ground-penetrating radar, it is ideal for efficiently searching for objects with low or no metal content.

The VMR3 “Minehound” dual-sensor detector is internationally proven. It is ideal for the simultaneous detection of metal and metal-free objects. This is a decisive advantage e.g. for the detection of IEDs.

Two different audio signals help the user distinguish between the ground-penetrating radar (GPR) and metal detector (MD). The MD provides a simple alarm while the GPR supplies acoustic information on the depth and dimension of the object. Based on the settings, the audio signals are visually supported by the LED display.

The VMR3 is also characterized by its mechanical features: The use of carbon and glass fibre-reinforced plastic makes it extremely rugged and durable.

It meets high standards for military mine clearance and humanitarian demining.

ACF Image

Specification

Metal detector (MD) and ground-penetrating radar (GPR) Sensor
Visual (LED)/audio/vibration Alarm Signal
8.5 hr Operating Time (LiPo)
6.5 hrs Operating Time (Alk)
102 x 43 x 17 cm (40.15 x 16.93 x 6.70 ") Case Dimensions
31.5 x 18 cm (12.40 x 7.09 ") Head Dimensions
4.0 kg (8.82 lbs) Detector Weight with Battery
3.54 kg (7.8 lbs) Detector Weight w/out Battery
IP68, 1.5m (1hr at 20 °C) Watertight
In accordance with MIL-STD-810F (F501.4-I, II, F502.4-I, II, F503.4-I, F506.4-III, F512.4-II, F516.5-IV) Ambient conditions
3.54 kg (7.8 lbs) Detector Weight w/out Battery
