S-Band Blade Antenna – 10-174
S-Band Blade Antenna – 10-174
The 10-174 antenna has been designed to provide omni-directional patterns at S-Band to support telemetry applications.
- ✔Datalink Antenna
- ✔PEEK shell
- ✔Very low profile
Specification
2250
Minimum Frequency
2450
Maximum Frequency
50
Impedence
≤1.5:1
Return Loss VSWR
>+4 dBi
Gain
Vertical
Polarization
Omnidirectional
Radiation Pattern Azimuth
1/4 Stub
Radiation Pattern Elevation
75
Peak Power Watts
84 x 20 x 29
Full Dimensions LxWxH mm
0.05
Mass kg
SMA
Connector Type
50000
Altitude ft
54
Continuous Operating Temperature Min - C
110
Continuous Operating Temperature Max C
MIL-STD-810F, Method 514.5, Procedure I, Category 5
Vibration
MIL-STD-810F
Standards
