Type 7-377 Diplexer
Type 7-377 Diplexer
The 7-377 diplexer operates over the frequency ranges of 30 MHz to 174 MHz and 225 MHz to 410 MHz. The diplexer comprises a low pass and a high pass filter connected in parallel at the input terminal. The electrical assembly is housed in a machined, aluminium alloy box, enclosed by an aluminium alloy baseplate. Three mounting holes provide for attachment to the mounting surface.
- ✔ allows two different devices to share a common communication channel using frequency-domain multiplexing
Specification
30
Minimum Frequency
410
Maximum Frequency
50
Impedence
Various see datasheet
Return Loss VSWR
100
Peak Power Watts
100
Average Power Watts
160.5 x 78 x 25
Full Dimensions LxWxH mm
0.5
Mass kg
N Female||TNC Female
Connector Type
35000
Altitude ft
55
Continuous Operating Temperature Min - C
70
Continuous Operating Temperature Max C
RTCA DO-160C, Section 8, Categories N and V
Vibration
