Vertically Polarized Omni Antenna – OA-1.4V-4.7V/2596

Vertically Polarized Omni Antenna – OA-1.4V-4.7V/2596

Dual Band (L/C Band), Vertically Polarized Omni Antenna, High gain L band version

  • ✔Designed for ground vehicle applications
  • ✔ Rugged design
  • ✔Integral spring
  • ✔Standard US/NATO 4 & 6 hole pattern
  • ✔Single connector
Awaiting product image
Click to enlarge

Specification

1350 Minimum Frequency
5000 Maximum Frequency
2:1 Max. Return Loss VSWR
6.5 Gain
Vertical Polarization
10 Peak Power Watts
2.1 Mass kg
N(F) Connector Connector Type
-40 Continuous Operating Temperature Min - C
70 Continuous Operating Temperature Max - C
